4 Axis Wood Cnc Router Machine , Accuracy Cnc Wood Cutting Machine
CNC router machine feature
1. Machine Body
Strong welded tubular steel frame and gantry moving mode, suitably strengthened the rigidity
that keeps stable and longtime work. Square welded steel tube frame, with the advantage of
high density and strength, which will enable the machine work in lifespan and keep the parallelism
between router and gantry.
2. Transimission
Y axis of CNC Router is equipped with double motors to keep stable moving. screw transmission.
Provide Positive Drive without slip, with high speed, high torque & high power. Taiwan Hiwin
square linear guide way with four-point contact design, enable to bear various direction loading,
which can ensure better load handling, together with steady movement to provide better mechanical precision.
3. Spindle
China changsheng water - cooling spindle, Original Imported Italian HSD spindle, original bearings.
Air-cooling the motor, forceful, with high concentricity and verticality. Long service life, stable operation.
water dooling spindle made in china can be optional.
4. Inverter
Fuling inverter, Taiwan Delta inverter optional, adjustable V / F curve and simple vector control,
16 big microprocessor controlled PWM output, automatic torque boost & slip compensation. low noise,
highly ensure the spindle working ability.
5. Drive
Our standard is Leadshine, Taiwan Delta / Japanese Panasonic / Yaskawa AC servo driving system
for you to choose. (1). Closed loop circuitry (2). Efficient (3). Capable of accelerating loads.
(4). Little noise. Change to Stepper driving is also available .
6. Control System
DSP / NcStudio / Mach3 control system.
CNC router machine application
1. Furniture
ideally suitable for processing cabinet door, wooden door, solid wood furniture,
panel wood furniture, windows, tables and chairs, etc.
2. Other wooden products
stereo box, computer desk, musical instruments, etc.
3. Well suited for processing panel, insulating materials, plastic, epoxy resin, carbon mixed compound, etc.
4. Decoration
acrylic, PVC, density board, artificial stone, organic glass, soft metals like aluminm and copper, etc.
CNC router machine parameter
working area 1400 * 1400 * 200 mm
Spindle 3.0 KW water cooling spindle (air cooling spindle for option)
Spindle rotating speed 24000 RPM
Motor Stepper ( servo for option)
Inverter FULING brand ( Taiwan DELTA for option)
Control system DSP / Mach3 / Nc studio
X,Y,Z Ball screw imported from Taiwan
Table surface Vacuum working table
Frame Cast Iron
Repositioning accuracy ± 0.01mm
Max. engraving speed 6,000mm / min
Max. motion speed 8,000mm / min
Tools diameter ER11 / ER20
Compatible software Type3, Ucancam, ArtCAM
Working supply AC220V, 1 phase, 50 / 60HZ (110V for option)
FAQ
1. How can I get the best router woodworking?
You can tell us your working materials details work by picture or video, so that we can judge
wether our machine can meet your need or not. Then we can give you the best model depends
on our experences.
2. This is the first time I use this kinds of machine, it is easy to operate?
We will send you manual and guide video in english, it can teach you how to operate the
machine.
3. The model is not suitable for me, do you have any model avaiable?
Yes, we can provide you many models, such as co2 laser engraving and cutting machine, co2 laser
marking machine, fiber laser marking machine, laser metal cutting machine, plasma cutting machine,
rotary router, stone cn router and so on.
4. How can i know that the router woodworking suitable for me ?
A. What materials do you want to engrave?
Different types cnc machine apply to different material.
B. What’s the max size of your material (Length * width * thickness)
Once you tell me this information of your material, then I'll recommend you the most suitable
machine and the best price for you. And we can also customize one for you or send you a solution.
