Parameters
No Description Parameter
1 X,Y,Z Working Area 300x300x100mm
2 Table Size 460x580x610mm
3 X,Y,Z Traveling Positioning Accuracy ±0.03/300mm
4 X,Y,Z repositioning Accura ±0.01mm
5 Table Surface Aluminum T slot table
6 Frame Cast Steel
7 X, Y,Z Structure Taiwan TBI ballscrew
8 Max. Power Consumption
(Without spindle)
0.8Kw9 Max. Rapid Travel Rate 6000mm/min
10 Max. Working Speed 4000mm/min
11 Spindle power 2.2kw
12 Spindle Speed 0-24000RPM
13 Drive Motors Stepper system
14 Working Voltage AC220V/50/60Hz
15 Command Language G code
16 Operating System Mach3
17 Interface USB
18 Flash Memory 128M( U Disk)
19 X,Y Resolution <0.01mm
20 Software Type3
21 Temperature 0°C~45°C
22 Relative humidity 30%~75%
23 Packing Size 880x830x860mm
24 Net Weight/Gross Weight 150KG/230KG
Features
1. X, Y, Z axis use imported ball bearing guide screws. It’s precise and fast. Even the letters of 1mm can be clearly discernible. The small-power machine uses large-power main axis, it’s an ideal product for manufacturing labels, construction models and moulds in batches.
2. High speed calculation It uses DSP64 contouring control system and FPGA technology which can continually and smoothly run the three axes with high speed. It has the ability of calculation of 5000 vector/s.
3. Steady data transmission .The data transmission uses the technology of ISA/IP DNC/IP straight association, which can associate the machine without interruption, and it has no limitation of the amount of the document.
4. Double-nut guide screw .It uses Germany-imported high-precision ball bearing guide screw which can eliminate cracks automatically. Coordinated with the imported shaft coupling, it can realize precise control. It uses straight line guide rail (cylinder or square), which can ensure the working life.
5. Large internal memory capacity of 32M is able to store 30 processing files simultaneously and open and process any of them.
6. Connection with the computer via USB interface enables data to be transmitted in a second, supports hot plug and play, no driver installation required.
Sample pictures
