Woodworking CNC Router Machine Water Cooling Spindle With Double Heads
1325 cnc router applications
Suitable in all kinds of wood ,like wood plate , wood crafts , wood funiture ,etc .
Also suit for advertisement,acrylic,PVC,PP electric wood plate. ABS plate,non-metetal material
to do the 3D processing plane cutting debossment,engraving .
1325 cnc router features
1. Machine with two independent heads.Can work in the same time.And do the same work.It is suitable for quantity production.More save time and labor.
2. The best quality China most popular water cooling spindle 3.0kw .With long time use and with high precision.
3. The vacuum pump holds tightly the carving materials which makes operating more reliable an convenient.
4. Leading rack rotation with high speed and strength.air speed can be 50m/min,when working in wave board also can be 25m/min.
5. Our software is compatible with type3/artcam/castmate/weitai and so on .
6. Advanced USB connection with DSP operating system,fast &smooth processing,our routers can completely work off-line.
7. The whole welding structure is shaped through tempeing treatment,making it solid and long lasting.
1325 cnc router optional parts
Driving system: Panasonic/Yaskawa/Delta servo system
Spindle: Italy HSD air cooling spindle, Chinese HQD air cooling spindle
Inverter:Taiwan Delta
Control system: DSP, Mach3, Syntec
Vacuum pump: Germany Becker pump, Chinese pump
Can equip rotating axis, lubricating system, mist cooling system and so on.
P.S.
All the pars of machine can do some changes to meet your requirements, such as the motor (step motor
or servo motor), spindle (air cooled or water-cooled ),inverter(DELTA or FULING) and the table of the machine also can be customized and so on
1325 cnc router parameter
Number Description Parameter
1 X/Y/Z working area 1300*2500*200mm
2 Table size 1410*3000mm
3 XYZ travel positioning accuracy ±0.01mm
4 XYZ repositioning positioning accury ±0.01mm
5 Table surface PVC
6 grantry steel
7 drive system X-Y axis Rack actuation
8 drive system Z axis Ball screw
9 Spindle power 3.0KW water cooling spindle(2 sets)
10 Max velocity 50m/min
11 Max working speed 25m/min
12 Spindle speed 0-24000rmp
13 work mode stepper motor and leadshine driver (optional servo)
14 Working voltage AC220V
15 Command language G code
16 Interface USB
17 Operating system NC studio control system(DSP / mach 3 for optional)
18 Flash memory 128
19 X-Y resolution 0.025mm
20 Software environment Wentai type3 artcam
21 Running environment Temperature:0-45°C
22 Paking size 3300*1900*1900mm
23 Net weight 1300 kg
24 Gross weight 1500 kg
1325 cnc router pictures
My skype: lingxiangcnc14
My email: export14
Product Image
