ELE 1530 ATC high - Precision woodworking cnc router
Features
China Changsheng water cooling spindle
Fuling inverter
FL118 motor and YAKO2811 bigger and stronger driver
DSP control system
Taiwan HIWIN Linear guide #20
Taiwan TBI ball screw
Parameter
ModelELE-1530
X,Y,Z travel( mm)1500 x3000 x220(can be customized)
Spindle power3KW water cooling spindle
Spindle rotation speed0-24000RPM
Tool colletER20
Max. Rapid Travel Rate60000mm/min
Max. Working Speed25000mm/min
X,Y,Z Traveling Positioning Accuracy±0.03/300mm
X,Y,Z Repositioning Accuracy±0.03mm
Table SurfaceVacuum and T-slot Combined
X, Y StructureGear and rack transmission, Taiwan HIWIN Linear Rail
Z StructureTaiwan TBI Ball Screw, Taiwan HIWIN Linear Rail
Drive MotorsFL118 motor and YAKO2811 driver
Controlling systemDSP
Working VoltageAC380V,3PH,50/60Hz (Option: 220V)
Safety Level
1, Soft limit switch (Shock absorption pad)
2, Japanese Omron limit switch
3, French Schneider electronics
4, French Schneider rotary safety switch on the control box
5, Wires, high soft shielding twisted-pair cable, fire-resistant and with low failure rate, could be be
-nt min 30,000,000 times
Application
1. WoodFurniture Industry: Wave Plate, fine pattern, antique furniture, wooden door, screen, craft sash, composite gates, cupboard doors, interior doors, sofa legs, headboards and so on.
2. Advertising industry: advertising identification, sigh making, Acrylic engraving and cutting, crystal word making, blaster molding, and other advertising materials derivatives making.
3. Die industry: A sculpture of copper, aluminum, iron and other metal molds, as well as artificial marble, sand, plastic sheeting, PVC pipe, wooden planks and other non-metallic mold.
4. Relief sculpture and 3D engraving
5. Cylindrical object
After-sale service
1 , Within 7 days since your local customs clearance: if the cnc router’s any parts has any problems, we will change it free.
2 , Exceed 7 days since your local customs clearance but within warranty period: if the cnc router parts have any problems, we can change the old machine parts to new ones free, but you should payall the shipping cost.
3 , Exceed warranty period: if the cnc router parts have any problems, we can offer new machine parts with cost price and you also should pay all the shipping cost.
4 , We offer 24 hours technical support by call, email
5 , Our technician can give you remote guide online(Skype or MSN,whatsapp) if you have any question
6 , We can record videos of operating the laser machine
7 , Free training course in our factory
8 . Machine will be adjusted before it is delivered , operation disk/CD was included.
Product Image
