CNC Wood Cutter Plywood Cutting Router Machine
Model: 1325V
This cnc wood cutter is widely used in plywood cutting, chipboard cutting, particle board cutting, slatwall cutting, furniture industry, furniture decoration industry, woodworking decoration industry, musical instrument industry, wooden crafts industry, etc. And this machine is suitable for large area plate engraving, solid wood furniture engraving, solid wood art murals carving, MDF carving and cutting, etc.
Features of plywood cutting CNC router:
1) Vacuum table in 6 zones can fix materials of different sizes effectively
2) Germany imported rolling balls screws, HIWIN square guide rails, high precision, large load bearing and stable running.
3) Gantry-travelling, sturdy, reliable and stable, non-deforming, high locating accuracy and save place.
4) Cut wood CNC Y axis use dual motor drive, select matching to ensure smooth movement.
5) DSP control system, with U disk available and not need computer ( can be completely off-line operation. ), provides high independence and great convenience for operation.
6) Unique ability to save several point of origin on several workpieces.
7) No engraving saw-tooth, smooth undersurface, legible contour, by high-power spindle.
8) Auto seeking original point system, a good way to improve the working efficiency.
9) Large compatibility of drawing software, such as Type3, artcam and some other CAD or CAM.
Application of cnc wood cut machine:
Woodworking Industry: stereo wave board processing, wooden door, various furniture product auxiliary processing, plywood cutting.
Advertising Industry: Advertising label, PVC plate, PCB board (drilling and engraving), Double color boards, logo production, acrylic cutting, plastic suction for making advertising dedication, word cutting, sign making, crystal word, LED display screen, kinds of doorplate, nameplate and so on.
Mold Industry: Apply for carving various molds, wood pattern, Foam mould, and metal mold, etc.
Musical instrument industry: instrument 3D surface engraving, shape cutting
Wooden crafts.
Exhibition industry: showcase, etc.
CNC Wood Cutter Parameters:
Working area: 1300x2500x200mm
Spindle type: China water cooled spindle (optional air cooled spindle)
Spindle power 4.5kw
Spindle rotating speed 0-24000rpm
Power supply: AC380±10, 50 HZ
Max moving speed: 35m/min
Max. working speed: 25m/min
Worktable: Vacuum suction table
Locating precision: <0.01mm
Min shaping character: Character:3x3mm,letter:2x2mm
Operating temperature: 5°C-40°C
Working humidity 30%-75%(without condensed water)
Working precision: ±0.05mm
System resolution: ±0.001mm
Control configuration: DSP A11
Data transfer interface: USB(offline)
System environment: WINDOWS 2000/WINDOWS XP/ windows 7
Spindle cooling way: water cooled
Graphic format supported: G code: *.u00, * mmg, * plt, *.nc
Compatible software ARTCAM, UCANCAM and other CAD or CAM software….
Cutting thickness: 0-70mm also (depends on different material)
Whole machine dimension: 3150x2150x1900(mm)
Net weight: 1250kgs
Gross weight 1300kgs
Packing Plywood case (veneer wood case for export)
Packaging & Delivery
Product Image
About Jinan Qingong Machinery Co.,Ltd
QINGONG MACHINERY belongs to QINGONG INTERNATIONAL GROUP, which is located in Jinan China and engaged in machinery and international business. Qingong Machinery is a professional CNC machine company, who produce and export CE approved cnc router, cnc laser, cnc plasma machines, spare parts and related products. These cnc machines are very helpful in woodworking, stone carving, advertising, mould making industries and so on.
At QINGONG, we are dedicated to providing exceptionally engineered products, technical support, and customer service at the lowest possible cost. Our focus is to help our customers realize goals in CNC by providing tools and resources to help transform concepts into real products.
Choosing Qingong, choosing the expert solutions for your machinery project.
