Woodpecker CNC router/ wood engraving machine
Woodpecker CNC router/ wood engraving machine:
Woodpecker CNC router / wood engraving machine AP-1325Y
*Features:
1. Step motor, ball screws, double Y-axis, imported linear guide,
DSC control system, 7 LCD controller, 3.7KW air-cooled spindle.
Powerful capability, high precision, fast speed, good durability.
2. Multiple functions: resume when restart, oblique cutting,
any-line restarting, various preset modes and customize mode for
option;
3.Compatible with CAD/CAM software, such as Type3 /Artcam /
Mastercam /Cimatron /Fastcam /Ucancam(Wentai) etc.
4.Optional accessories: servo motor, 0.5KW floating spindle,
multiple spindled, multi-spindled with simultaneous or independent
operations, extra-wide attaching plate(for spindle), vacuum table,
vacuum pump, dust collect head, dust collect pump etc..
5. Certificate: CE
6. Warranty: 1 year for machine, 6 months for spindle.
*Parameters:
Repeat positioning precision: ±0.05 mm
Spindle: 3.7 kw
Spindle rate: 24000 rpm
Cutting tool diameter: Φ3.175/Φ4/Φ6/Φ8/Φ12.7 mm
Max moving speed: 25 m/min
Working table size: 1360 x 3230 mm
Max travel range: 1300 x 2500 x 110 mm
Machine size: 1890 x 3500 x 1460 mm
Power supply: AC220V±10% /50HZ
Weight: 1080 kg
Consumption: 4.5 kw
*Woodpecker CNC router /CNC engraving machine has 3 series:
1) CP series: CP-6590, CP-1208, CP-1212, CP-1318, CP-1325Y,
CP-1530Y;
2) AP series: AP-6590Y, AP-1212Y, AP-1318Y, AP-1325Y, AP-1530Y
3) DP series: DP-6590, DP-1212, DP-1325
*ROC MESE manufactures:
CNC router, mold engraving machine, plasma cutting machine, foam cutter, flatbed UV printer, CNC notching machine, key making machine etc. Various configuration, sizes and customize service are available.
With the high quality, competitive price, and good after-sale
service, ROC™s machines are sold well in both domestic & overseas markets, and our registered brand
Woodpecker enjoys a high reputation there.
Product Tags: engraving machine flatbed uv printer key making machine
Woodpecker CNC router/ wood engraving machine images
ROC Machine Electronic System Engineering (Shanghai) CO., LTD
ROC MESE was founded in 1992 in Shanghai China, has an office
area >3,000m2 and factory space >30,000m2.
ROC MESE professionally manufactures CNC router, CNC mould
engraving machine, CNC plasma cutting machine, CNC foam cutter,
CNC printer, CNC notching machine, CNC key making machine etc.
Various configurations, sizes, and customize service are available.
With the high quality, favorable price, and super after-sale service,
ROC's machines are sold well in both domestic & overseas
markets, and its registered brand "Woodpecker" enjoys a high
reputation there.
